-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Parameter | Specification |
|---|---|
| Product Type | M12 Circular Connector (Male, Straight) |
| Gender | Male (Pin) |
| Connector Style | Straight cable mount |
| Contacts | 4-pin (D-coding) |
| Current Rating | 4A per contact |
| Voltage Rating | 250V AC/DC |
| Contact Material | Gold-plated brass |
| Insulation Material | PBT (Polybutylene Terephthalate) |
| Housing Material | Nickel-plated brass |
| IP Rating | IP67 (when mated) |
| Operating Temperature | -25°C to +85°C |
| Cable Gland Size | 4-8mm diameter |
| Locking Mechanism | Screw locking (M12×1 thread) |
| Mating Cycles | ≥100 cycles |
| Wire Gauge | 24-20 AWG (0.2-0.5mm²) |
| Shielding | 360° shielding available |
| Certifications | CE, RoHS |
| Cable Exit | Straight |
