-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Property | Value |
|---|---|
| Manufacturer Part No | 239544 (20 m) |
| Cable Type | Basic cable |
| Drive Technology System | B&R |
| Number of Cores & Cross-section | (5x(2×0.14) + 2×0.5)C |
| Outer Diameter (mm) | 8 |
| Weight per km (kg/km) | 75 |
| Copper Index (kg/km) | 45 |
| Min. Bend Radius, e-chain (x d) | 10 |
| Min. Bend Radius, e-chain (mm) | 80 |
| Min. Bend Radius, Flexible (x d) | 8 |
| Min. Bend Radius, Fixed (x d) | 5 |
| Temperature, e-chain (°C) | +5 to +70 |
| Temperature, Flexible (°C) | -5 to +70 (DIN EN 60811-504) |
| Temperature, Fixed (°C) | -15 to +70 (DIN EN 50305) |
| Max Speed Unsupported (m/s) | 5 |
| Max Speed Gliding (m/s) | 3 |
| Max Acceleration (m/s²) | 30 |
| Nominal Voltage (V) | 50 |
| UL Voltage Rating (V) | 300 |
| Test Voltage (V) | 500 |
| Conductor | Tinned copper wires, finely stranded |
| Core Insulation | High-quality TPE mixture |
| Core Stranding | Per measuring system specification |
| Core Group 1 | 5x(2×0.14) |
| Core Group 1 Color Code | brown/green, yellow/grey, white/violet, red/black, pink/blue |
| Core Group 2 | 2×0.5 |
| Element Shield | Tinned copper, 90% optical coverage |
| Element Jacket | TPE mixture for e-chain® |
| Overall Shield | Tinned copper braid, ~55% linear, ~80% optical |
| Outer Jacket | Oil-resistant PVC (DIN EN 50363-4-1) |
| Outer Jacket Color | Yellow-green (RAL 6018) |
| UV Resistance | None |
| Oil Resistance | DIN EN 50363-4-1, Class 2 |
| Flame Retardant | IEC 60332-1-2, VW-1, FT1, FT2 |
| Silicone-Free | Yes (PV 3.10.7 – 1992) |
| UL Verified | V293650 (igus 4-year guarantee) |
| NFPA | NFPA 79-2018, Chapter 12.9 |
| REACH Compliant | Yes |
| RoHS Compliant | Yes (2011/65/EU) |
| Cleanroom | ISO Class 2 (DIN EN ISO 14644-1) |
| CE Certification | 2014/35/EU |
| Connector A | Round plug, socket |
| Connector B | SUB-D, pin |
