-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Parameter | Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Part Number | 1598534 |
| Series | PLC-RSC |
| Type | Relay Terminal Block |
| Contact Configuration | 1 CO (SPDT) |
| Rated Voltage | 24V DC |
| Switching Current | 6A |
| Switching Voltage | 250V AC / 30V DC |
| Contact Material | Silver alloy |
| Electrical Life | 100,000 operations (at 6A) |
| Mechanical Life | 10,000,000 operations |
| Coil Power Consumption | 0.9W |
| Operating Temperature | -40°C to +60°C |
| Response Time | ≤8ms (operate), ≤4ms (release) |
| Isolation Voltage | 4kV |
| Connection Type | Screw terminals |
| Wire Size | 0.08-2.5mm² (AWG 28-14) |
| Mounting | DIN rail TS35 |
| Housing Material | Polyamide (PA66) |
| Protection Class | IP20 |
| Dimensions | 17.5 x 90 x 64 mm (WxHxD) |
| Weight | 120g |
| Certifications | UL, CSA, cULus, CE, RoHS |
