-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Detail |
|---|---|---|
| General | Product Type | Han® 2A Industrial Connector (Male) |
| Series | Han® 2A Standard | |
| Housing Material | Polyamide (PA) Black | |
| Electrical | Voltage Rating | 250V AC/DC |
| Current Rating | 16A per contact | |
| Contact Configuration | 8 poles (customizable) | |
| Contact Material | Brass, gold-plated | |
| Mechanical | IP Rating | IP65/IP67 (when mated) |
| Mating Cycles | ≥1,000 | |
| Locking Mechanism | Push-pull locking | |
| Cable Entry | M16 threaded | |
| Environmental | Operating Temperature | -40°C to +85°C |
| Shock Resistance | 100G (6ms) | |
| Certifications | Standards | IEC 61076-2-101 |
| Approvals | CE, UL, RoHS, REACH | |
| Physical | Dimensions (W×H×D) | 40×40×55mm |
| Weight | ~120g (without cable) | |
| Color Coding | Black housing with blue latch |
