-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Mavic 3 Series, Air 2S, Mini 3 Pro |
| Type | Function | Hybrid Power/Signal Cable (Gimbal to Main Board) |
| Electrical | Voltage Rating | 3.3V/5V/12V DC (Multi-rail) |
| Current Capacity | 3A Continuous (12V Power), 1A (5V), 500mA (3.3V) | |
| Connector | Type | 24-pin JST-GH (Main Board), 18-pin Micro ZIF (Gimbal Side) |
| Locking Mechanism | Positive-latch IP67 connectors | |
| Data Transmission | Protocol | 4-Lane MIPI CSI-2 + CAN FD 2.0 + I²C |
| Bandwidth | 24Gbps (4K/120fps capable) | |
| Mechanical | Cable Length | 85mm (Precision length for compact routing) |
| Outer Diameter | 4.2mm (Including shielding) | |
| Bend Radius | 15mm (Dynamic), 10mm (Static) | |
| Materials | Conductor | 7N Oxygen-Free Copper (20AWG Power/28AWG Signal) |
| Insulation | High-Temp Silicone (300°C rated) | |
| Shielding | Triple-layer (Foil + Braid + Conformal Coating) | |
| Environmental | Operating Temperature | -40°C to +105°C |
| Vibration Resistance | MIL-STD-810G, Method 514.7 | |
| Durability | Flex Life | >100,000 cycles (At rated bend radius) |
| Certification | Standards | UL 3030, EN 62368-1, RoHS 3.0 |
| Included | Package Contents | 1x Cable Assembly, 2x M2.5 Mounting Clips, Installation Guide |
