-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Matrice 300 RTK, Matrice 350 RTK (With DJI Dock) |
| Type | Function | High-Speed Data & Power Transmission (Dock to Drone) |
| Electrical | Voltage Rating | 48V DC (Operating Range: 36-60V) |
| Current Capacity | 10A Continuous (15A Peak) | |
| Data Transmission | Protocol | 10G Ethernet + CAN FD 2.0 (Dual-Channel) |
| Bandwidth | 10Gbps (Ethernet), 5Mbps (CAN FD) | |
| Connector | Dock Side | 16-pin IP68 Hybrid (MIL-DTL-38999 Series III) |
| Drone Side | 12-pin IP67 Aviation Connector | |
| Mechanical | Cable Length | 1.5m (Standard Length) |
| Outer Diameter | 8.2mm (Including shielding) | |
| Bend Radius | 60mm (Dynamic), 40mm (Static) | |
| Materials | Conductor | Silver-Plated Copper (16AWG Power/24AWG Signal) |
| Insulation | PTFE (260°C Rated) | |
| Shielding | Penta-Layer (Foil + Braid + Spiral + Carbon Fiber + Conformal Coating) | |
| Environmental | Operating Temperature | -40°C to +85°C |
| Vibration Resistance | MIL-STD-810H, Method 514.7 | |
| Certification | Standards | UL 3030, EN 62368-1, MIL-DTL-27500 |
| Included | Package Contents | 1x Cable Assembly, 4x M4 Stainless Clamps, Installation Toolkit |
