-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
Model: DJIYC.XC.DD000376.06
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Systems | DJI O3 Air Unit |
| Electrical | Operating Voltage | 7.4V-26.4V (2S-6S LiPo) |
| Current Capacity | 5A Continuous (8A Peak) | |
| Connector Type | 10-pin IPEX (O3 Side) / 8-pin JST-GH (Peripheral Side) | |
| Mechanical | Cable Length | 30cm (Precision Length) |
| Wire Gauge | 18AWG (Power) / 24AWG (Signal) | |
| Weight | 28g | |
| Materials | Conductor | 7N Oxygen-Free Copper |
| Insulation | High-Temp Fluoropolymer (260°C rated) | |
| Shielding | Quad-Layer EMI Protection (Foil+Braid+Spiral+Drain Wire) | |
| Environmental | Operating Temp | -40°C to 105°C |
| Bend Cycles | >50,000 (At 15mm radius) | |
| Features | Protection | IP67-rated connectors, Corrosion-Resistant Contacts |
| Signal Integrity | Twinaxial Design for 4K/120fps Transmission | |
| Certification | Standards | MIL-DTL-38999 (Connectors), RoHS, REACH, CE |
| Pinout | O3 Side (10-pin) | 1-2:VBAT, 3-4:GND, 5-6:HDMI_DATA, 7-8:UART, 9:5V, 10:STATUS |
| Peripheral Side (8-pin) | 1-2:5V_OUT, 3-4:GND, 5:SBUS, 6:PWM, 7:ADC, 8:LED | |
| Included | Package Contents | 1x Cable Assembly, 4x M3 Lock Washers, IPEX Removal Tool, Installation Manual |
