-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Ronin 2, Inspire 3, Zenmuse X9 Gimbal |
| Type | Function | 3-Axis Brushless Motor Driver Module |
| Electrical | Operating Voltage | 26V DC (18-34V Range) |
| Peak Current | 8A per Axis (3s Duration) | |
| Continuous Current | 3A per Axis | |
| Control | Communication Protocol | CAN FD (5Mbps) + RS485 (Backup) |
| Encoder Resolution | 24-bit Absolute Magnetic Encoder | |
| Mechanical | Dimensions | 48mm × 38mm × 12mm (L×W×H) |
| Weight | 68g | |
| Mounting | 4x M3 Threaded Holes (Vibration-Isolated) | |
| Performance | Torque Output | 2.5Nm (Peak), 0.8Nm (Continuous) |
| Angular Accuracy | ±0.01° (Static), ±0.05° (Dynamic) | |
| Vibration Suppression | >30dB Reduction (10-500Hz) | |
| Environmental | Operating Temperature | -30°C to +75°C (Heated Operation Below 0°C) |
| IP Rating | IP54 (Module), IP67 (Connectors) | |
| Materials | Housing | Magnesium Alloy (AZ91D) |
| PCB | 8-Layer HDI with 3oz Copper | |
| Certification | Standards | MIL-STD-810H, EN 61373 (Railway Vibration) |
| Included | Package Contents | 1x Driver Module, 2x Damping Pads, Thermal Interface Material, Mounting Screws |
