-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Details |
|---|---|---|
| Compatibility | Supported Models | Inspire 2 (All Configurations) |
| Function | Primary Use | Connects Stereo Vision Sensors to Main FC |
| Interface | Connector Type | 16-pin ZIF (0.5mm pitch) x2 |
| Electrical | Voltage Rating | 5V DC ±5% |
| Data Bandwidth | 60fps Stereo Vision Transmission | |
| Material | Base Material | 3-Layer Polyimide FPC |
| Thickness | 0.2mm ±0.03mm | |
| Durability | Bend Radius | ≥6mm (static) |
| Flex Cycles | ≥15,000 (DJI test standard) | |
| Environmental | Operating Temperature | -20°C to 65°C (-4°F to 149°F) |
| Dimensions | Length | 180mm (main branch) |
| Width | 8mm (widest section) | |
| Shielding | EMI Protection | Dual-Layer Copper + Aluminum Shielding |
| Signal | Protocol | MIPI CSI-2 (Dual Channel) |
