-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
*(Applicable to all Phantom 4 models: Standard/Pro/Pro V2.0/Advanced/RTK)*
| Category | Specification |
|---|---|
| Compatibility | Phantom 4 (All variants) |
| Cable Type | 40-pin hybrid coaxial-flex cable |
| Voltage | 12V DC (Gimbal motors) / 5V DC (Camera electronics) |
| Current Rating | 2.5A (Peak 3.5A for motor startup) |
| Data Protocol | Custom DJI HD Video Link + CAN Bus 2.0B |
| Max Resolution | 4K/60fps (Pro models) / 1080p/60fps (Standard) |
| Cable Length | 150mm (Main harness) + 80mm (Camera flex) |
| Bend Radius | 8mm (Static) / 12mm (Dynamic) |
| Shielding | Quad-shielded (Foil + Braid + Spiral + Conformal Coating) |
| Connector Type | 40-pin IP67 aviation connector (Main) / 24-pin ZIF (Camera) |
| Wire Gauge | 20AWG (Power) / 26AWG (Signal) |
| Materials | OFC conductors + Liquid Crystal Polymer insulation |
| Operating Temp | -20°C to +70°C |
| Vibration Resistance | MIL-STD-810G, Method 514.7 |
| Key Features | • Redundant power lines • Moisture-resistant conformal coating • Auto-recovery circuit protection |
