-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Matrice 300 RTK, Matrice 350 RTK |
| Type | Function | Intelligent Power Distribution Hub |
| Electrical | Input Voltage | 44.4V (6S LiPo, Range: 36-60V DC) |
| Output Channels | 4x Isolated Outputs: 12V@8A, 5V@5A, 3.3V@2A, 48V@15A (Peak) | |
| Efficiency | 96% (Typical at Full Load) | |
| Connector | Type | 16-pin Aviation Grade (MIL-DTL-38999 Series III) |
| Contact Rating | 25A per pin (Gold-plated contacts) | |
| Communication | Protocol | CAN Bus 2.0B (1Mbps) |
| Telemetry | Real-Time Monitoring of Voltage/Current/Temp on All Channels | |
| Mechanical | Dimensions | 85mm × 65mm × 22mm (L×W×H) |
| Weight | 220g | |
| Mounting | 6x M4 Threaded Inserts (Vibration-resistant) | |
| Materials | Housing | CNC-machined Aluminum (Hard-anodized) |
| PCB | 8-layer FR-4 with 3oz Copper | |
| Environmental | Operating Temperature | -40°C to +85°C (Heated operation below -20°C) |
| IP Rating | IP67 (When connectors properly mated) | |
| Vibration Resistance | MIL-STD-810G, Method 514.7 (Category 24) | |
| Protection | Features | Over-Current/Over-Voltage/Reverse Polarity/Short-Circuit Protection |
| Redundancy | Dual Input Power Paths with Auto-Switching | |
| Certification | Standards | DO-160G (Aircraft), EN 62368-1, UL 60950-1 |
| Included | Package Contents | 1x PDM Module, 2x Power Cables, Thermal Pad, Mounting Hardware |
