-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Mavic 3 / Mavic 3 Cine / Mavic 3 Classic |
| Component Type | Function | Gimbal Flex Cable Assembly (Primary signal/power interface) |
| Electrical | Voltage Rating | 3.3V (Logic), 5V (Sensors), 12V (Motors) |
| Current Capacity | 2.0A Peak (Motor Drive), 600mA Continuous (Signals) | |
| Connector | Type | 36-pin Ultra-High-Density ZIF (0.25mm pitch) |
| Data Transmission | Protocol | 6-Lane MIPI CSI-2 (Supports 5.1K/50fps & 4K/120fps) |
| Control Signals | I²C (12.5MHz), SPI, 2x CAN FD Buses | |
| Mechanical | Cable Length | 62mm (Precision length for 3-axis gimbal) |
| Thickness | 0.18mm (14-layer stacked flex PCB) | |
| Bend Radius | 1.5mm (Dynamic) / 1.0mm (Static) | |
| Materials | Conductor | Gold-Palladium Alloy (40AWG, 7N purity) |
| Insulation | Liquid Crystal Polymer (LCP) – 320°C solderable | |
| Shielding | Penta-Shielded (Per-lane + global EMI/RFI protection) | |
| Environmental | Operating Temperature | -30°C to +85°C (Heated gimbal mode below 0°C) |
| Humidity Resistance | 95% RH Non-condensing (96hr test passed) | |
| Durability | Flex Life | >200,000 cycles (MIL-STD-883H compliant) |
| Certification | Standards | IPC-6013 Class 3A, MIL-PRF-31032 |
