-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Matrice 300 RTK (All M1/M2 Arm configurations) |
| Electrical | Voltage Rating | 48V DC (Max operating voltage) |
| Current Capacity | 15A Continuous (20A Peak) | |
| Connector Type | 12-pin IP68 Aviation Connector (Gold-plated contacts) | |
| Power Delivery | Wire Gauge | 12AWG (Power) / 20AWG (Signal) |
| Voltage Drop | <0.5V @ 15A (End-to-end) | |
| Mechanical | Cable Length | 0.8m (M1 Arm) / 1.2m (M2 Arm) |
| Cable Diameter | 10.5mm | |
| Weight | 320g (M1) / 450g (M2) | |
| Materials | Conductor | 99.99% Oxygen-Free Copper |
| Insulation | Cross-linked Polyethylene (XLPE) | |
| Jacket Material | Abrasion-resistant PVC (Oil/UV resistant) | |
| Environmental | Operating Temperature | -40°C to +85°C |
| Water Resistance | IP68 (Submersible to 1m for 30 mins) | |
| Durability | Vibration Resistance | MIL-STD-810G, Method 514.7 |
| Flex Life | >100,000 cycles (At minimum bend radius) | |
| Protection | Circuit Safeguards | Short-circuit/Over-current/Reverse polarity protection |
| Certification | Standards | UL 3030, EN 60332-1-2, RoHS 3.0 |
| Pinout | Power Pins (4x) | 48V+, 48V-, Chassis GND (2x) |
| Signal Pins (8x) | CAN Bus, PWM, Telemetry, Reserve | |
| Included | Package Contents | 1x Arm Harness, 2x M4 Locking Screws, Installation Manual |
