-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Details |
|---|---|---|
| Compatibility | Supported Systems | DJI FPV Air Unit (Part of DJI Digital FPV System) |
| Function | Primary Use | GPS Module to Air Unit Connection |
| Interface | Connector Type | 6-pin Micro ZIF (Zero Insertion Force) |
| Electrical | Voltage Rating | 3.3V DC ±5% |
| Signal Type | UART (TX/RX) + Power Delivery | |
| Material | Base Material | 2-Layer Polyimide FPC with Reinforcement |
| Thickness | 0.15mm ±0.02mm | |
| Durability | Bend Radius | ≥3mm (static) / ≥5mm (dynamic) |
| Flex Cycles | ≥8,000 cycles | |
| Environmental | Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity Resistance | IP54 (splash resistant) | |
| Dimensions | Length | 120mm (including connectors) |
| Width | 5.2mm (at widest point) | |
| Performance | Data Rate | 9600 baud (default GPS baudrate) |
| Shielding | EMI Protection | Full-length copper shielding |
