-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Matrice 350 RTK, Matrice 30 Series (Dual-Battery Configuration) |
| Electrical | Chemistry | LiPo 6S (High-Energy Density) |
| Capacity | 4280mAh (97.6Wh) @ 0.2C Discharge | |
| Voltage Range | 17.4V (Min) – 25.2V (Max) | |
| Performance | Max Continuous Current | 15A (Standard), 30A (Boost Mode for 30s) |
| Charge Current | 6A (Standard), 12A (Fast Charge) | |
| Energy Efficiency | ≥95% (Discharge-Charge Cycle) | |
| Physical | Dimensions | 140mm × 50mm × 60mm (L×W×H) |
| Weight | 720g | |
| Connector Type | DJI Enterprise Quick-Release (Gold-Plated, 8-Pin) | |
| BMS | Protection Features | Over-Charge/Discharge/Current/Temp/Cell Imbalance |
| Communication | CAN Bus 2.0B (Real-Time Data Transmission) | |
| Environmental | Operating Temperature | -20°C to +50°C (Discharge), 0°C to +45°C (Charge) |
| Storage Temperature | -10°C to +30°C (Recommended) | |
| IP Rating | IP54 (Dust/Water Resistant) | |
| Durability | Cycle Life | 400 Cycles (To 80% Capacity) |
| Shelf Life | 12 Months (At 50% Charge) | |
| Smart Features | Self-Discharge | Auto-Discharges to Storage Voltage (3.85V/Cell) After 10 Days |
| Firmware Updates | Field-Upgradable via DJI Pilot 2 App | |
| Certification | Standards | UN38.3, UL 2054, IEC 62133, CE, FCC |
| Included | Package Contents | 1x Intelligent Battery, Safety Manual, Storage Case |
