-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
Model: DJIBC.EN.SS000404.01
| Category | Parameter | Specification |
|---|---|---|
| Basic Info | Battery Type | LiPo 4S (Lithium Polymer High-Density) |
| Capacity | 6000mAh | |
| Voltage | 15.4V (Nominal), 17.6V (Max Charged) | |
| Performance | Energy | 92.4Wh |
| Max Discharge Current | 45A (Continuous) | |
| Max Charge Current | 10A (With Fast Charger) | |
| Physical | Dimensions | 155×60×50mm (L×W×H) |
| Weight | 850g | |
| Connector Type | Proprietary DJI Enterprise Quick-Release | |
| Protection | Safety Features | 8-Level Protection (Overcharge/Discharge/Short Circuit/Temp/Current/Voltage/etc) |
| Smart Features | Communication | CAN Bus 2.0B (Real-time data transmission) |
| Self-Discharge | Auto-discharge to 3.8V/cell after 10 days | |
| Battery Management | Individual Cell Monitoring & Balancing | |
| Environment | Operating Temp | -20°C to 50°C (Discharge), 5°C to 45°C (Charge) |
| Storage Temp | -10°C to 30°C (Recommended) | |
| IP Rating | IP55 (Dust protected, Water jet resistant) | |
| Durability | Cycle Life | 500 cycles (To 80% capacity) |
| Compatibility | Supported Models | Matrice 30 Series, Matrice 350 RTK (With adapter) |
| Certification | Standards | UN38.3, RoHS, CE, FCC, KC |
| Included | Package Contents | 1x Smart Battery, 1x Quick Start Guide |
