-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Air 2S (All versions) |
| Electrical | Operating Voltage | 3.3V DC (Logic) / 5V DC (Motor/Sensor) |
| Current Rating | 1.2A Max (Peak Motor Load) | |
| Connector Type | 28-pin High-Density ZIF (0.3mm pitch) | |
| Signal | Data Transmission | 4-Lane MIPI CSI-2 + I²C + SPI + UART |
| Video Resolution | Supports 5.4K/30fps & 4K/60fps | |
| Mechanical | Cable Length | 58mm (Precision length for 3-axis gimbal) |
| Thickness | 0.25mm (12-layer flex construction) | |
| Bend Radius | 2.5mm (Dynamic) / 1.8mm (Static) | |
| Materials | Conductor | Gold-Palladium Alloy (38AWG) |
| Insulation | Liquid Crystal Polymer (LCP) | |
| Shielding | Quad-layer EMI Protection (Foil+Braided+Sputtered+Conformal) | |
| Environmental | Operating Temperature | -25°C to +75°C |
| Humidity Resistance | 95% RH Non-condensing (96hr test passed) | |
| Durability | Flex Life | >60,000 cycles (Under rated bend conditions) |
| Features | Protection | ±15kV ESD Protection / Over-Current Protection |
| Certification | Standards | IPC-6013 Class 3 / MIL-PRF-31032 |
| Pinout | Video Lanes (16x) | 4× MIPI D-PHY (4.5Gbps/lane) |
| Control Lines (8x) | I²C (2x), SPI (2x), UART (2x), GPIO (2x) | |
| Power (4x) | 3.3V, 5V, GND (2x) | |
| Included | Package Contents | 1x Signal Cable, Alignment Jig, ESD Wrist Strap |
