-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Agras T50, T25 (All Configurations) |
| Electrical | Voltage Rating | 5V DC Operating Voltage |
| Current Capacity | 2A Max (Signal Lines) | |
| Connector Type | 8-pin Aviation-grade Connector (Both Ends) | |
| Signal | Data Transmission | CAN Bus 2.0B Protocol |
| Baud Rate | 1Mbps | |
| Noise Immunity | >100V/m (EN 61000-4-3 Compliant) | |
| Mechanical | Cable Length | 1.2m (Standard Field Configuration) |
| Outer Diameter | 6.5mm | |
| Weight | 120g/m | |
| Materials | Conductor | 7/0.1mm Tinned Copper |
| Insulation | Dual-layer PE+PVC (Oil/UV Resistant) | |
| Shielding | 96% Coverage Spiral Shield + Drain Wire | |
| Environmental | Operating Temp | -40°C to 85°C |
| IP Rating | IP67 (When Connected) | |
| Flex Life | >50,000 Cycles (Under Load) | |
| Durability | Tensile Strength | >80N |
| Abrasion Resistance | >5,000 Rubs (EN 50305-4-3) | |
| Certification | Standards | MIL-C-27500, EN 50289-1-6, RoHS 3.0 |
| Pinout | Pin 1-2 | CAN_H/CAN_L (Twisted Pair) |
| Pin 3-4 | Power/GND (18AWG) | |
| Pin 5-8 | Reserved (Shielded) | |
| Included | Package Contents | 1x Signal Cable, 2x Connector Dust Caps, Installation Manual |
