-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
Model: DJI-PWR-SDC-2
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Systems | DJI Digital FPV Systems (O3 Air Unit, Goggles Integra, Avata) |
| Electrical | Input Voltage | 7.4V-52.8V (2S-12S LiPo) |
| Output Voltage | 9V/12V (Auto-Switching) | |
| Max Current | 6A Continuous (8A Peak) | |
| Connector Type | XT60 Input / DJI 8-Pin Output (Upgraded connector) | |
| Power | Efficiency | >92% (Peak Efficiency) |
| Power Dissipation | <4W at Full Load | |
| Mechanical | Dimensions | 55mm × 35mm × 18mm (L×W×H) |
| Weight | 60g | |
| Cable Length | 12cm Input / 20cm Output (Extended length) | |
| Materials | Enclosure | Reinforced Nylon Composite |
| Internal Components | Dual MOSFET Design, Japanese Capacitors | |
| Features | Protection | Over-Current/Voltage/Temperature, Reverse Polarity Protection |
| Cooling | Aluminum Heat Sink + Passive Cooling | |
| Environmental | Operating Temp | -30°C to 70°C (Extended range) |
| Storage Temp | -40°C to 85°C | |
| Certification | Standards | RoHS, CE, FCC Compliant |
| Included | Package Contents | 1x Power Module, 1x 8-Pin Cable, 1x Mounting Bracket, Quick Start Guide |
