-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Parameter | Specification |
|---|---|---|
| Compatibility | Supported Models | Mavic 3 Series (Including Cine), Air 2S, Mini 3 Pro |
| Type | Function | High-Speed Gimbal Signal & Power Hybrid Cable |
| Electrical | Voltage Rating | 3.3V (Logic), 5V (Sensors), 12V (Motors) |
| Current Capacity | 2.5A Peak (Motor Drive), 800mA Continuous (Signals) | |
| Connector | Type | 34-pin Ultra-HD ZIF (0.25mm pitch, IP6X Dustproof) |
| Data Transmission | Protocol | 8-Lane MIPI CSI-2 (Supports 5.1K/60fps & 4K/120fps) |
| Additional Signals | I²C (25MHz), SPI, 2x CAN FD Buses | |
| Mechanical | Length | 68mm (Mavic 3), 55mm (Air 2S), 48mm (Mini 3 Pro) |
| Thickness | 0.2mm (16-layer stacked flex) | |
| Bend Radius | 1.8mm (Dynamic), 1.2mm (Static) | |
| Materials | Conductor | Gold-Palladium Alloy (40AWG, 7N purity) |
| Insulation | Liquid Crystal Polymer (LCP) + Polyimide Hybrid | |
| Shielding | Hexa-Shielded (Foil+Braided+Sputtered+Conformal) | |
| Environmental | Operating Temp | -30°C to +85°C (Heated gimbal mode below 0°C) |
| Vibration Resistance | MIL-STD-810H, 20G Shock/1000Hz Vibration | |
| Durability | Flex Life | >150,000 cycles (Consumer), >300,000 cycles (Enterprise) |
| Certification | Standards | IPC-6013 Class 3A, MIL-PRF-31032/6 |
