-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Category | Specification | Engineering Details |
|---|---|---|
| Motor Architecture | Hybrid Stepper | NEMA 34 Frame (86×86mm) |
| Full Part Number | 3004-307-10M | With 10-pin hybrid connector |
| Electrical | ||
| Step Resolution | 1.8° (±0.03°) | Laser-tested accuracy |
| Phase Current | 7.0 A/phase (RMS) | 10A peak capability |
| Phase Resistance | 0.35 Ω ±5% | 4-wire measurement @ 25°C |
| Phase Inductance | 2.2 mH ±10% | 1kHz, 1V RMS sine wave |
| Insulation Resistance | >100MΩ @ 500VDC | UL 1004-1 compliant |
| Mechanical | ||
| Shaft Configuration | Dual-keyed hollow shaft | 15mm bore with 5mm keyway |
| Bearing System | Angular contact pair | ABEC-5 precision rating |
| Rotor Dynamics | 1800 g-cm² inertia | With tungsten balance weights |
| Axial Play | <0.01mm | Pre-loaded bearing design |
| Thermal | ||
| Thermal Time Constant | 55 minutes | From 25°C to 130°C |
| Thermal Resistance | 0.8°C/W | Junction-to-case |
| Connector System | ||
| Connector Type | 10M (Hybrid Power+Signal) | MIL-DTL-5015 compliant |
| Contact Rating | 10A/pin (power), 2A (signal) | Gold-plated contacts |
| Environmental | ||
| IP Rating | IP69K | Steam-cleaning capable |
| Shock Resistance | 150G, 11ms | MIL-STD-202G Method 213B |
| Vibration | 20G, 10-2000Hz | 3-axis testing |
