-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Parameter | Specification | Details |
|---|---|---|
| Motor Type | Hybrid Stepper Motor | NEMA 34 Frame (86×86mm) |
| Model Number | 3004-305-10M | Full manufacturer designation |
| Step Angle | 1.8° (±0.05°) | 200 steps/revolution |
| Holding Torque | 3.0 Nm (425 oz-in) | At rated current |
| Rated Current | 5.0 A/phase (RMS) | Optimal operating current |
| Phase Resistance | 0.6 Ω ±8% | 25°C measurement |
| Phase Inductance | 3.5 mH ±15% | 1kHz test frequency |
| Rotor Inertia | 1100 g-cm² | Mechanical characteristic |
| Shaft Configuration | Dual shaft (front/rear) | 9.53mm diameter, keyed front |
| Body Length | 104mm (4.09″) | Excluding shafts |
| Weight | 3.8 kg (8.4 lbs) | With connectors |
| Insulation Class | Class F (155°C) | Enhanced thermal rating |
| Temperature Range | -30°C to +80°C | Extended operational range |
| IP Rating | IP67 | Submersible protection |
| Connector Type | 10M (10-pin) | Hermetically sealed |
| Back EMF Constant | 42 V/1000 rpm | Voltage generation characteristic |
