-Highly Customizable
Wire harnesses can be tailored to specific customer requirements, including connector types, cable lengths, wire gauges, and electrical configurations—ideal for diverse industries and applications.
-Stable and Wide Market Demand
Wire harnesses are essential in automotive, robotics, industrial automation, medical devices, and consumer electronics, ensuring consistent and long-term demand.
-High Value-Added Products
Compared to standard wires or cables, wire harnesses integrate multiple components such as connectors, terminals, and protective sleeves—offering higher margins and added value.
-Preferred by OEMs and Integrators
Pre-assembled wire harnesses simplify installation and save labor costs for end customers, making them attractive to OEM manufacturers and system integrators.
| Parameter | Specification | Details |
|---|---|---|
| Motor Type | Hybrid Stepper Motor | NEMA 34 Frame (86×86mm) |
| Model Number | 3004-307-5M | Complete manufacturer designation |
| Step Angle | 1.8° (±0.05°) | 200 steps/revolution |
| Holding Torque | 4.2 Nm (595 oz-in) | At rated current |
| Rated Current | 7.0 A/phase (RMS) | Optimized for high-power applications |
| Phase Resistance | 0.35 Ω ±8% | 25°C measurement |
| Phase Inductance | 2.2 mH ±15% | 1kHz test frequency |
| Rotor Inertia | 1350 g-cm² | Mechanical characteristic |
| Shaft Configuration | Single shaft (keyed) | 12.7mm (1/2″) diameter |
| Body Length | 112mm (4.41″) | Excluding shaft |
| Weight | 4.5 kg (9.9 lbs) | With 5M connector |
| Insulation Class | Class H (180°C) | High-temperature capability |
| Temperature Range | -40°C to +100°C | Extreme environment operation |
| IP Rating | IP65 (connector area) | Dust-tight/water-resistant |
| Connector Type | 5M (9-pin) | High-current industrial connector |
| Back EMF Constant | 38 V/1000 rpm | Voltage generation characteristic |
