| Category | Specification |
|---|---|
| Manufacturer | KUKA |
| Part Number | 00‑182‑465 |
| Cable Type | Robot Hybrid Cable (Power + Signal) |
| Application | KUKA KRC4 Controller to Robot Arm |
| Number of Conductors | 4G1.5 + (2×2×0.34)C |
| Conductor Material | Tinned Copper |
| Outer Diameter | Approx. 12.5 mm |
| Sheath Material | PUR, oil-resistant and abrasion-resistant |
| Sheath Color | Orange |
| Rated Voltage | 300/500 V |
| Test Voltage | 2000 V AC |
| Temperature Range | -30°C to +80°C (fixed), -5°C to +70°C (flexible) |
| Minimum Bend Radius | 10× outer diameter (flexing) |
| Cable Weight | Approx. 195 kg/km |
| Shielding | Overall Foil Shield with Drain Wire |
| Flame Retardant | IEC 60332-1 |
| Oil Resistance | Yes |
| Halogen Free | Optional |
| Standards Compliance | CE, RoHS |
